A low-power 6V brushed DC gearmotor with a 98.78:1 metal spur gearbox. The cylindrical motor body measures just under 25mm in diameter, and the D-shaped output shaft is 4mm in diameter, extending 12.5mm from the gearbox face plate. The low-power variant draws less current than the HP version, making it suitable for battery-powered applications. Also available with an integrated encoder for closed-loop control.

Specifications

• Gear Ratio – 98.78:1
• Voltage – 6V
• No-Load Speed – 61 RPM
• No-Load Current – 100mA
• Stall Torque – 9.1 kg·cm (130 oz·in)
• Stall Current – 2.0A
• Motor Diameter – ~25mm
• Output Shaft – 4mm D-shaped, 12.5mm length
• Gearbox – Metal spur gears
• Dimensions – 25D × 54L mm

Also Available

• 99:1 Metal Gearmotor 25D×54L HP 6V – High-power variant with more torque and speed
• 99:1 Metal Gearmotor 25D×54L MP 12V with Encoder – Medium-power 12V with integrated encoder

Ideal For

• Battery-powered robotics
• Low-current motorised mechanisms
• Projects requiring moderate torque with lower power draw

Package Contents

• 1× 99:1 Metal Gearmotor 25D×54L mm LP 6V
