An adapter board designed to make adding wireless point-to-point or mesh networking with XBee modules straightforward. Features an onboard 3.3 V regulator, level-shifting circuitry for safe 5 V logic connection, and a breadboard-friendly pinout. Compatible with FTDI cables for direct USB computer connection.

This is an unassembled kit including the PCB and all necessary components. Soldering is required — a quick build suitable for beginners.

Key Features

• Onboard 3.3 V Regulator – Clean power supply for XBee modules, up to 250 mA
• 5 V Level Shifting – Safe connection to Arduino and other 5 V microcontrollers
• Two Status LEDs – Activity (RSSI) and power (Associate) indicators
• 10-Pin 2 mm Sockets – Included for easy module swapping and protection
• Breadboard-Friendly – Commonly used pins brought out along the edge
• FTDI Compatible – Connect to a computer via USB using an FTDI cable for configuration and firmware updates
• Broad Compatibility – Works with XBee Series 1, Series 2, and Pro modules

Specifications

• Regulator Output – 3.3 V, up to 250 mA
• Logic Level – 5 V tolerant with level shifting
• XBee Socket – 10-pin 2 mm pitch
• Compatible Modules – XBee Series 1, Series 2, Series 1 Pro, Series 2 Pro

Package Contents

• 1× XBee Adapter PCB
• All SMD and through-hole components for assembly
• 1× 10-pin 2 mm socket set

Ideal For

• Wireless sensor networks
• Point-to-point and mesh communication
• Arduino wireless projects
• IoT prototyping with XBee modules
