A robust 6-pin GX16 aviation-style connector set including both the panel-mount jack and mating plug. The threaded locking ring screws onto the panel connector, creating a secure connection that won't pull apart — ideal for signal or power wiring in enclosures.

Key Features

• Locking Connection – Threaded ring screws onto the panel jack for a secure, vibration-proof fit
• 6 Solder-Cup Pins – Easy to wire on both the jack and plug sides
• Panel Mount – Fits a 15.5mm mounting hole with included lock washer and nut
• Strain Relief – Clamp on the plug end secures cables up to 5mm diameter
• Labelled Pins – Clearly marked on both connector and plug for easy wiring

Specifications

• Connector Type – GX16 aviation connector
• Pins – 6
• Mounting Hole – 15.5mm diameter
• Termination – Solder cup
• Cable Clamp – Up to 5mm diameter

Ideal For

• Enclosure panel wiring for robotics and CNC
• Multi-conductor signal and power connections
• Removable connections that need mechanical security

Package Contents

• 1× Panel-mount jack with lock washer and nut
• 1× Mating plug with strain relief

Resources

• Datasheet (GX16 pinout diagram)
