The 0.100″ (2.54 mm) 2×7-Pin Straight Female Header is a double-row, 14-pin socket strip designed to mate with standard 0.1″ pitch male headers. The 2×7 layout provides a medium-density connection point suitable for a range of embedded and prototyping applications.

A 14-pin dual-row configuration is commonly used for extended JTAG interfaces, custom module connections, and breakout boards that require more pins than a standard 2×5 header.

Key Features

• 0.1″ (2.54 mm) Pitch – Industry-standard spacing compatible with breadboards and perfboard
• Straight Orientation – Mounts perpendicular to the PCB for standard vertical connections
• 2×7-Pin Configuration – Double-row, 14-position socket
• Through-Hole Mounting – Solders directly to standard PCBs

Ideal For

• Extended JTAG and debug interfaces
• Custom module and breakout board connections
• Board-to-board interconnects
• Prototyping and PCB design

Package Contents

• 1× 0.100″ (2.54 mm) 2×7-Pin Straight Female Header
