An analog LED strip featuring both RGB and warm white (~3000K) LEDs at 60 LEDs per metre on a weatherproof white flexi PCB. Control the entire strip at once using any microcontroller and four transistors (one per channel) — no addressable LED library needed, just PWM for colour mixing.

Power the strip with 9–12V DC and ground the R, G, B, and W pins through NPN transistors or N-channel MOSFETs to activate each colour channel. The weatherproof silicone coating makes it suitable for indoor use and light outdoor use. Cut lines every 5cm (3 LEDs) let you trim to the exact length you need.

Key Features

• RGBW (Warm White ~3000K) – Full RGB colour mixing plus a dedicated warm white channel
• 60 LEDs per Metre – Bright, even illumination
• Analog Control – Simple PWM via transistors, no addressable LED protocol needed
• Weatherproof – Silicone coating on white flexi PCB for indoor and light outdoor use
• Cuttable Every 5cm – Trim to length at marked cut lines (3 LEDs per segment)
• Solderable Pads – 0.1" copper pads for easy wiring

Specifications

• LED Type – RGB + Warm White (~3000K)
• LED Density – 60 LEDs/m
• Power Supply – 9–12V DC
• Control – Analog (ground R/G/B/W channels via transistors)
• PCB Colour – White
• Cut Interval – Every 5cm (3 LEDs)
• Reel Length – 4m (sold per metre)

Ideal For

• Decorative lighting and art installations
• Costuming and wearable projects
• Bike and vehicle accent lighting
• Ambient room and under-cabinet lighting

Resources

• Adafruit RGB LED Strip Tutorial (add a 4th transistor for the white channel)
