The 0.100″ (2.54 mm) Shorting Block is a removable jumper with a closed-top blue housing, designed to bridge two adjacent pins on a standard 0.1″ pitch male header. Shorting blocks are essential for configuring hardware settings, selecting operating modes, and enabling or disabling features on PCBs.

The closed-top design prevents accidental contact with other components and keeps the jumper securely in place. The blue colour provides easy visual identification and can be used for colour-coded configuration schemes on boards with multiple jumper positions.

Key Features

• 0.1″ (2.54 mm) Pitch – Fits standard male header pins
• Closed-Top Housing – Protects against accidental shorts and provides a secure grip for removal
• Blue Colour – Easy visual identification, ideal for colour-coded configurations
• Removable Design – Quickly reconfigure hardware settings without soldering

Ideal For

• Hardware configuration and mode selection
• Colour-coded jumper schemes on multi-option boards
• Prototyping and development boards
• Replacing lost or damaged jumpers

Package Contents

• 1× 0.100″ (2.54 mm) Shorting Block (Blue, Top Closed)
