The 0.100″ (2.54 mm) 1×8-Pin Right-Angle Female Header provides a reliable perpendicular connection point for standard 0.1″ pitch male headers. Its right-angle orientation is ideal for low-profile builds or board-edge connections where vertical clearance is limited.

This single-row, 8-pin socket header is well suited for interfacing with SPI buses, display modules, sensor breakouts, and other peripherals that use an 8-pin header arrangement.

Key Features

• 0.1″ (2.54 mm) Pitch – Industry-standard spacing compatible with breadboards and perfboard
• Right-Angle Orientation – Mounts parallel to the PCB for low-profile or edge connections
• 1×8-Pin Configuration – Single-row, 8-position socket
• Through-Hole Mounting – Solders directly to standard PCBs

Ideal For

• SPI and display module connections
• Sensor and peripheral breakout boards
• Low-profile enclosure builds
• Prototyping and custom wiring harnesses

Package Contents

• 1× 0.100″ (2.54 mm) 1×8-Pin Right-Angle Female Header
